TNC(RP TNC) Connector features: quick connection: using a push-pull connection method, simple and fast; Reliable sealing: using high-quality sealing materials to ensure the airtightness of the connection; Strong durability: Made of high-quality materials, it has good pressure resistance, wear resistance, and corrosion resistance; Multiple types: According to different application requirements, there are multiple types to choose from, including straight through, corner, T-shaped, etc; Safe and reliable: Equipped with a safety lock function, the pins will be securely locked in the connected state to prevent accidental detachment and loosening.
TNC(RP TNC) Connector features: quick connection: using a push-pull connection method, simple and fast; Reliable sealing: using high-quality sealing materials to ensure the airtightness of the connection; Strong durability: Made of high-quality materials, it has good pressure resistance, wear resistance, and corrosion resistance; Multiple types: According to different application requirements, there are multiple types to choose from, including straight through, corner, T-shaped, etc; Safe and reliable: Equipped with a safety lock function, the pins will be securely locked in the connected state to prevent accidental detachment and loosening.
| Plating | Nickel/gold |
| Material | Brass |
| Insulator | PTFE/Plastic |
| ROHS | IS09001:2015 |
| Pin contact | Brass |
| Risilent contact | Beryllium copper |
| O-ring seling | 6146 silicon |
| Elastic contact | Tin brass with gold or sliver plated |
| Produce equipment | CNC |
| Connector type | smc male rg316 |
TNC connector performance:
1. Pressure resistance performance: generally able to withstand high working pressure, usually between 0.5MPa and 1.6MPa;
2. Temperature resistance: It has good temperature resistance within a certain range and can adapt to the temperature requirements of different working environments;
3. Flow characteristics: With a large flow area and good fluid channel design, it can achieve large flow transmission and provide stable gas supply;
4. Durability: After rigorous durability testing, it has a long lifespan and stable performance.
