Low Loss RF Jumper，High-quality 10cm SMC Female to SMA Female coaxial cable assembly using RG174 cable. Ideal for compact RF connections and IoT devices. 100% tested for VSWR & continuity.
Key attributes
| Conductor Material | Copper |
| Insulation Material | PTFE |
| Jacket | PVC |
| Number of Conductors | 1 |
| Model Number | SMC Female to SMA Female for RG174 Cable Assembly |
| Cable Type | RG174 cable |
| Brand Name | BJDZ |
| Place of Origin | Jiangsu, China |
| Application | RF |
| Plating | Nickel |
| Material | Copper |
| Insulator | PTFE/Plastic |
| Certificate | CE/FCC/ROHS/ISO9001:2015 |
| Length | 10CM |
| Frequency Range (MHz) | DC-6GHz |
| Max Voltage | 335V max |
| Temperature range | -55~+155°C (PE Cable -40~+85°C) |
| Input Impendence (ohm) | 50 |
| V.S.W.R | 1.15+0.02f |
| Vibration | 100m/s2 (10~500Hz) |
| Withstand Voltage | 2500V r.m.s at sea level |
| Working Voltage | 1000Vr.m.s at sea level |
| Insertion Loss | ≤ 0.24dB/6GHz |
| Insulation resistance | ≥5000mΩ |
| Max Input Power (w) | 50 |
| Contact resistance | Center Contact ≤3mΩ |
| Center conductor retention force | 450N |
| Durability | ≥ 500(cycles) |
| Contact resistance | CenterContact ≤1mΩ Outer Contact ≤1mΩ |
| Voltage Standing Wave Ratio | Straight ≤ 1.15/6GHz Right angle ≤ 1.25/6GHz |
Packaging and delivery
| Selling Units | Single item |
| Single package size | 14X0.6X0.6 cm |
| Single gross weight | 0.350 kg |
Lead time
| Quantity (pieces) | Lead time (days) |
| 1 - 1000 | 10 |
| 1001 - 5000 | 15 |
| 5001 - 10000 | 25 |
| > 10000 | To be negotiated |
Price
| US$1.25-2.85 | |
| 20 - 499 pieces | US$1.18 |
| 500 - 999 pieces | US$1.15 |
| 1000 - 4999 pieces | US$1.12 |
| >= 5000 pieces | US$1.00 |
Cable Type: RG174 / Coax Cable
Connectors: SMC Type Female Jack to SMA Female
Length: 10cm (Custom lengths available upon request)
Application: IoT, PCB Interconnects, Compact Electronics, Test Equipment
Certification: RoHS, ISO9001
MOQ: 1 Piece (Sample order supported)
This 10cm SMC Female to SMA Female RG174 Cable Assembly is a precision-engineered RF jumper designed for high-frequency signal transmission in compact electronic systems. Manufactured by Zhenjiang Binjiang Electronic Co., Ltd., a verified high-tech enterprise with strict quality control systems, this cable assembly ensures reliable connectivity between SMC and SMA interface devices.
The use of RG174 cable provides a balance of flexibility and low signal loss, making it suitable for internal connections where space is limited. This assembly is widely used in wireless communication modules, IoT sensors, and testing fixtures.
Precision Connectors: Features high-grade SMC Female Jack and SMA Female connectors ensuring secure, low-reflection connections.
Optimized Length: The 10cm (4-inch) length is ideal for short-hop connections on PCBs or within tight enclosures, minimizing signal latency and clutter.
High Flexibility: Utilizes RG174 coaxial cable, known for its excellent flexibility, making it easy to route in confined spaces without damaging the internal dielectric.
Superior Performance: Engineered for low insertion loss and stable VSWR (Voltage Standing Wave Ratio) across a wide frequency range.
Durable Construction: Brass body with nickel or gold plating options (depending on specification) for corrosion resistance and long-term mating durability.
Quality Assured: 100% inspected for continuity, insulation resistance, and VSWR before shipment.
Parameter | Value |
Cable Part Number | RG174 / RG174/U |
Connector A | SMC Type Female (Jack) |
Connector B | SMA Female |
Standard Length | 100 mm (10 cm) |
Impedance | 50 Ohm |
VSWR | ≤ 1.2:1 (Typical) |
Frequency Range | DC to 3 GHz (SMA), DC to 10 GHz (SMC) |
Center Contact | Brass, Gold Plated |
Outer Body | Brass, Nickel Plated |
Insulation | PTFE (Polytetrafluoroethylene) |
Jacket | PVC (Polyvinyl Chloride) |
Operating Temperature | -55°C to +125°C |
IoT & M2M Devices: Connecting antennas or modules in compact smart devices.
PCB Interconnects: Bridging RF signals between daughterboards and motherboards.
Test & Measurement: Used as pigtails in RF test fixtures and calibration labs.
Wireless Modules: Connecting Wi-Fi, Bluetooth, or GPS modules to main antennas.
Medical Electronics: Internal cabling for portable medical monitoring equipment.
Factory Direct Supply
We are Zhenjiang Binjiang Electronic Co., Ltd., a leading manufacturer of RF connectors and cable assemblies based in Jiangsu, China. With over 10 years of OEM/ODM experience, we supply partners of Fortune 500 companies.
Quality Guarantee
Our factory operates under ISO9001 standards and is TÜV Rheinland assessed. We utilize advanced comprehensive testing equipment to ensure every piece meets international quality benchmarks.
Customization Service
While this listing is for a standard 10cm RG174 assembly, we offer full customization services:
Length: Any length from 1cm to 100m.
Cable Type: Upgrade to RG316, LMR195, or semi-rigid cables for higher performance.
Connectors: Change termination types (e.g., SMA Male, N-Type, RP-SMA) or plating colors.
Logo: Custom printing or laser marking on the cable or connectors.
Fast Delivery
Sample Orders: Processed within 1-3 working days.
Bulk Orders: Competitive lead times with global shipping options (DHL, FedEx, Sea/Air freight).
Standard Package:
1 pc / Polybag
100 pcs / Anti-static Bag (Optional)
Custom retail packaging available.
Select the quantity.
Click "Add to Cart" or "Request a Quote" for bulk/OEM inquiries.
For custom specifications, please contact our sales team directly.
Note: Prices shown are for reference only. Final pricing depends on order quantity and specific customization requirements.
