Reliability: The design of cable components is durable, maintaining performance even in harsh environments and providing stable, uninterrupted connections.
Customization: One of the prominent features of cable components is their strong adaptability. Customized cable components can meet specific requirements, allowing integration of various connectors, lengths, and shielding options. Cable components can be customized to meet specific requirements for integration.
| Temperature range | -40~+60°C |
| Vibration | 100m/s2 (10~500Hz) |
| Impedance | 50 OHM |
| Frequency Range | DC – 1GHz |
| Working Voltage | 170V max |
| Break-down Voltage | 4000V rms @ sea level |
| Contact resistance | Center Conductor ≤2mΩ |
| Average power | 3KW max |
| Insulation resistance | ≥ 1000 MΩ |
| VSWR | Straight ≤ 1.20 Right angle ≤ 1.30 |
| Durability (mating) | ≥500 (cycles) |
Quality Assurance:Strict adherence to ISO/IEC international standards ensures that products achieve industry-leading levels in weather resistance, signal stability, and other key indicators;
Global Service Network:Experienced engineers provide 24/7 technical support, real-time consultation, and troubleshooting. Our products are widely used in cutting-edge applications including 5G base stations, satellite communications, and smart IoT, with customers worldwide, covering 30 countries and regions in Europe, the Americas, Asia Pacific, and other regions.
