Efficiency: Cable components can optimize signal transmission, reduce energy loss, and ensure that power, data, or audio reaches their destination with minimal interference.
Reliability: The design of cable components is durable, maintaining performance even in harsh environments and providing stable, uninterrupted connections.
| Temperature range | -40~+85°C |
| Vibration | 100m/s2(10-500Hz) |
| Impedance | 50 Ohm |
| Frequency Range | DC – 11GHz |
| Working Voltage | 2700V max |
| Break-down Voltage | 4000V rms @ sea level |
| Contact resistance | ≤0.4 OHM @ inner contact ≤1.5 OHM @ outer contact |
| Average power | 3KW max |
| Insulation resistance | 10000M OHM |
| VSWR | ≤1.10 |
| Durability (mating) | ≥500 (cycles) |
Technical Strength: Experienced R&D team and standardized laboratories provide one-stop service from prototype development to mass production;
Quality Assurance: Strict adherence to ISO/IEC international standards ensures that products achieve industry-leading levels in weather resistance, signal stability, and other key indicators;
