Reliability: The design of cable components is durable, maintaining performance even in harsh environments and providing stable, uninterrupted connections.
Organization: Cable components help achieve clean and orderly wiring, simplify maintenance and troubleshooting work, and save time and resources.
| Temperature range | -55~+155°C (PE Cable -40~+85°C) | |
| Vibration | 98m/S2 (10~2000Hz), 10g | |
| Impedance | 50Ω | |
| Frequency Range | DC-12.4GHz(semi-rigid cable DC-18 GHz) | |
| Insertion Loss | ≤ 0.15dB/6GHz | |
| Working Voltage | 335Vr.m.s at sea level | |
| Break-down Voltage | 1000V r.m.s at sea level | |
| Contact resistance | CenterContact ≤ 3mΩ Outer Contact ≤ 2.5mΩ | |
| Average power | 3KW max | |
| Insulation resistance | ≥ 5000 MΩ | |
| VSWR | Straight | flex cable ≤ 1.10+0.02f Semi-rigid cable ≤ 1.07+0.018f |
| Right angle | flex cable ≤ 1.20+0.03f Semi-rigid cable ≤ 1.17+0.02f | |
| Durability (mating) | ≥500 (cycles) | |
Quality Assurance: Strict adherence to ISO/IEC international standards ensures that products achieve industry-leading levels in weather resistance, signal stability, and other key indicators;
Flexible Customization: OEM/ODM solutions, including rapid prototyping, parameter selection, performance testing, and system optimization, meeting the stringent application requirements of industries such as telecommunications, and aerospace;
