High Performance：Low VSWR, low insertion loss, high shielding effectiveness, dustproof and waterproof, high and low temperature resistance, high insertion/removal cycles (fatigue resistance)
Multiple Interfaces：Various interface types and cable compatibility
High Shielding Effectiveness
| Temperature range | -40~+85°C |
| Vibration | 100m/s2(10-500Hz) |
| Impedance | 50 Ohm |
| Frequency Range | DC – 7.5GHz |
| Working Voltage | 2700V max |
| Break-down Voltage | 4000V rms @ sea level |
| Contact resistance | ≤0.4 OHM @ inner contact ≤1.5 OHM @ outer contact |
| Average power | 3KW max |
| Insulation resistance | 10000M OHM |
| VSWR | Straight≤ 1.10 Right angle ≤ 1.25 |
| Durability (mating) | ≥500 (cycles) |
Precision CNC machining: Using 4-axis and 5-axis CNC machine tools, precision machining can be carried out according to the requirements of different structures, ensuring the dual guarantee of mechanical and electrical performance of the product.
Binjiang Electronics is a high-tech private company that integrates research and development, production, and sales. By continuously innovating core technologies and leading advantages in segmented fields, we focus on providing a full range of signal interconnection products, solutions, and services to core customers in multiple industries and fields worldwide.
