Zhenjiang Binjiang Electronic Co., Ltd.-RF technology expert, core business full range of RF products:adapter/connector/antenna/coaxial cable, customized services: OEM/ODM support, including fast sampling, testing optimization Top 500 enterprise suppliers with technological advantages, certified internationally, 24-hour technical response, focusing on 5G/satellite communication fields, global services, product coverage in over 30 countries, and aerospace grade quality assurance Corporate vision: To drive the development of wireless communication technology through innovation.
| Temperature range | -40~+85°C |
| Vibration | 100m/s2(10-500Hz) |
| Impedance | 50 Ohm |
| Frequency Range | DC – 6GHz |
| Working Voltage | 2700V max |
| Break-down Voltage | 4000V rms @ sea level |
| Contact resistance | ≤0.4 OHM @ inner contact ≤1.5 OHM @ outer contact |
| Average power | 3KW max |
| Insulation resistance | 10000M OHM |
| VSWR | ≤1.10 |
| Durability (mating) | ≥500 (cycles) |
Binjiang Electronics is a high-tech private company that integrates research and development, production, and sales. By continuously innovating core technologies and leading advantages in segmented fields, we focus on providing a full range of signal interconnection products, solutions, and services to core customers in multiple industries and fields worldwide.
Connecting the world and co creating the future "is the enduring mission of Binjiang Electronics. We strive to build a fully connected world through signal interconnection products, solutions, and services, continuously creating value for customers and society.
