Customization: One of the prominent features of cable components is their strong adaptability. Customized cable components can meet specific requirements, allowing integration of various connectors, lengths, and shielding options. Cable components can be customized to meet specific requirements for integration.
Reduce interference: Carefully designed cable components can minimize electromagnetic interference (EMI) and electromagnetic compatibility (EMC) issues, ensuring clear and uninterrupted signals.
| Temperature Range | -55~+155°C (PE Cable -40~+85°C) | |
| Impedance | 50Ω | |
| Vibration | 98m/S2 (10~2000Hz), 10g | |
| Frequency Range | DC-12.4GHz(semi-rigid cable DC-18 GHz) | |
| Insertion Loss | ≤ 0.15dB/6GHz | |
| Withstanding Voltage | 1000V r.m.s at sea level | |
| Working Voltage | 335Vr.m.s at sea level | |
| Insulation Resistance | ≥ 5000 MΩ | |
| Center conductor retention force | 450N | |
| Durability | ≥ 500(cycles) | |
| Contact resistance | CenterContact ≤ 3mΩ Outer Contact ≤ 2.5mΩ | |
| Voltage Standing Wave Ratio | Straight | flex cable ≤ 1.10+0.02f Semi-rigid cable ≤ 1.07+0.018f |
| Right angle | flex cable ≤ 1.20+0.03f Semi-rigid cable ≤ 1.17+0.02f | |
We have strict requirements for product materials, performance, and design. We use advanced computer simulation algorithms and structural optimization to improve RF solutions, and have accumulated years of structural solutions and unique manufacturing processes to further optimize RF indicators. We often conduct pre design manufacturing and cost analysis, and customize corresponding products according to different customer needs, demanding the strictest standards for our own product quality.
Assembly line: We have a professional assembly OEM production base that can provide you with high-quality RF and microwave component processing services.
