Optimize signal transmission in compact spaces with our precision-engineered RF coaxial cable. Designed for RG316 compatibility, this 70cm jumper features dual SMB male connectors with gold-plated straight pins, delivering ultra-low signal loss (≤0.53dB/100m @400MHz) across -70°C to +200°C environments. Ideal for 5G modules, IoT devices, and aerospace instrumentation.
Key attributes
| Conductor Material | Copper |
| Insulation Material | PTFE |
| Jacket | PVC |
| Number of Conductors | 1 |
| Model Number | SMB Male to SMB Male for RG316 Jumper Pigtail |
| Cable Type | RG316 Cable |
| Brand Name | BJDZ |
| Place of Origin | Jiangsu, China |
| Application | RF |
| Plating | Nickel |
| Material | Copper |
| Insulator | PTFE/Plastic |
| Certificate | CE/FCC/ROHS/ISO9001:2015 |
| Length | 70CM |
| Frequency Range (MHz) | DC-12.4GHz |
| Max Voltage | 335V max |
| Temperature range | -55~+155°C (PE Cable -40~+85°C) |
| Input Impendence (ohm) | 50 |
| V.S.W.R | 1.15+0.02f |
| Vibration | 100m/s2 (10~500Hz) |
| Withstand Voltage | 2500V r.m.s at sea level |
| Working Voltage | 1000Vr.m.s at sea level |
| Insertion Loss | ≤ 0.24dB/6GHz |
| Insulation resistance | ≥5000mΩ |
| Max Input Power (w) | 50 |
| Contact resistance | Center Contact ≤3mΩ |
| Center conductor retention force | 450N |
| Durability | ≥ 500(cycles) |
| Contact resistance | CenterContact ≤1mΩ Outer Contact ≤1mΩ |
| Voltage Standing Wave Ratio | Straight ≤ 1.15/6GHz Right angle ≤ 1.25/6GHz |
Lead time
| Quantity (pieces) | Lead time (days) |
| 1 - 1000 | 10 |
| 1001 - 5000 | 15 |
| 5001 - 10000 | 25 |
| > 10000 | To be negotiated |
Price
| 20 - 499 pieces | US$1.26 |
| 500 - 4,999 pieces | US$1.21 |
| 5,000 - 9,999 pieces | US$1.09 |
| >= 10,000 pieces | US$0.92 |
Packaging and delivery
| Selling Units | Single item |
| Single package size | 22X15X310 cm |
| Single gross weight | 1kg |
Military-Grade Durability
FEP jacket withstands extreme temperatures (-70°C to +200°C) + chemical corrosion
High-Speed Signal Integrity
50Ω impedance ±3% tolerance | 94pF/m capacitance | 70% signal velocity
Space-Saving Design
Ultra-flexible 2.9mm diameter cable bends at 15mm radius
Zero-Error Connectivity
Gold-plated contacts resist oxidation | Push-lock SMB coupling (4GHz max freq)
Tested Reliability
15kg/km tensile strength | 7x0.18mm silver-coated copper strands
Parameter | Value |
Connector Type | SMB Male (Straight Pin) to SMB Male |
Cable Type | RG316 Coaxial |
Length | 70cm (27.5") |
Impedance | 50Ω ±3% |
Attenuation | 0.875dB/m @1GHz |
Operating Temp | -70°C to +200°C |
Conductor Material | Silver-Coated Copper |
Jacket Color | Brown FEP |
Telecom: 5G repeaters, base station antennas
Medical: Patient monitors, imaging equipment
Industrial: Robotics control systems, PLCs
Automotive: GPS trackers, radar sensors
Aerospace: Avionics test benches, satellite comms
Plug-&-Play: Pre-assembled with strain relief collars
RoHS/REACH Compliant
Custom Lengths Available (Contact for OEM options)
