This FRP ISM fiberglass antenna delivers 5.8dBi high gain across the 860MHz–930MHz frequency band, engineered specifically for outdoor long-range wireless communication systems. Featuring an N Male connector and integrated lightning arrester design, it provides reliable signal performance in harsh environmental conditions while protecting connected equipment from surge damage.
Constructed with UV-resistant fiberglass reinforced plastic (FRP) housing and precision-tuned radiating elements, this omnidirectional antenna ensures consistent coverage and durability for continuous outdoor deployment. The robust mechanical structure withstands extreme temperatures, moisture, and wind loads, making it ideal for mission-critical IoT and telemetry networks where maintenance access is limited.
Designed for LoRaWAN gateways, smart metering infrastructure, industrial monitoring systems, and rural broadband applications, this antenna supports OEM/ODM customization including adjustable frequency tuning, alternative connector types, custom mounting brackets, and modified cable lengths. Rapid prototyping and small-batch production are available to meet tight project timelines without compromising quality or performance consistency.
Parameter | Specification | ||
Frequency Range | 860 MHz – 930 MHz | ||
Gain | 5.8 dBi | ||
Impedance | 50 Ω | ||
VSWR | ≤ 1.5:1 | ||
Polarization | Vertical | ||
Horizontal Beamwidth | 360° | ||
Vertical Beamwidth | Approx. 30° | ||
Max Input Power | 100 W | ||
Connector Type | N Male | ||
Lightning Protection | Integrated Arrester | ||
Housing Material | UV-Resistant FRP (Fiberglass) | ||
Operating Temperature | -40°C to +85°C | ||
Wind Survival Rating | ≥ 200 km/h | ||
Mounting Thread | Standard Mast Mount | ||
Weight | Approx. 450 g | ||
●High Gain Performance: Delivers 5.8dBi gain across 860–930MHz ISM band for extended communication range and improved link budget in LoRaWAN and IoT deployments.
●Integrated Lightning Arrester: Built-in surge protection safeguards sensitive RF equipment against transient voltage spikes, reducing field maintenance costs and system downtime.
●UV-Resistant FRP Housing: Fiberglass reinforced plastic enclosure resists UV degradation, corrosion, and moisture ingress for reliable multi-year outdoor operation in coastal and industrial environments.
●Full Omnidirectional Coverage: 360° horizontal radiation pattern eliminates alignment requirements, simplifying installation on towers, poles, and rooftop masts.
●Wide Operating Temperature Range: Certified performance from -40°C to +85°C ensures stable operation in arctic cold, desert heat, and tropical humidity without parameter drift.
●Flexible OEM/ODM Customization: Supports custom frequency tuning, connector options, mounting hardware, and branding with rapid prototyping and small minimum order quantities.
●International Certification Compliance: Meets CE, ROHS, FCC, and ISO/IEC standards, ensuring regulatory acceptance across European, North American, and Asia-Pacific markets.
●LoRaWAN Gateway Networks
●Smart Metering & Utility AMI Systems
●Industrial IoT Sensor Networks
●Agricultural Telemetry & Precision Farming
●Rural Broadband Wireless Access
●Environmental Monitoring Stations
●Asset Tracking & Fleet Management
●Oil & Gas Remote Site Communications
●Smart City Infrastructure Nodes
●Drone Communication Relay Systems
As a Fortune Global 500 partner serving customers in over 80 countries with a 99% positive feedback rating on Alibaba International, Zhenjiang Binjiang Electronic delivers proven RF solutions backed by 24/7 engineering support. Every antenna undergoes rigorous testing per ISO/IEC standards to ensure batch-to-batch consistency matching approved samples.
●Custom frequency tuning within 800MHz–1GHz ISM bands
●Alternative connector options (SMA, TNC, DIN, 4.3-10)
●Modified mast mount brackets and pole clamp sizes
●Custom cable assembly lengths and connector configurations
●Private labeling and custom packaging design
●Rapid prototyping within 5–7 business days
●Small batch MOQ starting from 50 units
●Full OEM/ODM workflow from design review to mass production
What is an FRP ISM fiberglass antenna used for in 860MHz-930MHz applications?
An FRP ISM fiberglass antenna operating at 860MHz–930MHz is specifically designed for LoRaWAN, smart metering, and industrial IoT networks requiring long-range outdoor coverage. The fiberglass housing provides superior weather resistance compared to plastic alternatives, while the integrated arrester protects gateway equipment. This frequency band is globally allocated for license-free ISM communications, making it ideal for scalable IoT deployments across Europe, Asia, and the Americas.
How does the integrated lightning arrester protect my LoRaWAN gateway equipment?
The built-in lightning arrester in this 860MHz–930MHz fiberglass antenna diverts transient voltage surges caused by nearby lightning strikes or electrostatic discharge safely to ground before they reach your sensitive RF transceiver. This eliminates the need for separate inline surge protectors, reduces installation complexity, and prevents costly equipment failures. For optimal protection, ensure proper grounding of the antenna mast and N Male connector interface during installation.
Can I customize the frequency range or connector type for my specific IoT project?
Yes, we offer full OEM/ODM customization for this FRP fiberglass antenna including retuning to any sub-GHz ISM frequency, swapping the N Male connector to SMA, TNC, or DIN types, and modifying mounting hardware dimensions. Our engineering team provides revised specifications and prototype units within 5–7 business days for validation. Small batch orders from 50 units are supported, enabling cost-effective pilot deployments before committing to volume production.
What makes this fiberglass antenna more durable than standard plastic outdoor antennas?
Unlike ABS or PVC housings that become brittle under prolonged UV exposure, our FRP (fiberglass reinforced plastic) enclosure maintains structural integrity and RF transparency for over 10 years in direct sunlight, salt spray, and industrial pollution. The material’s low thermal expansion coefficient prevents internal element detuning across -40°C to +85°C operating ranges. Combined with sealed N Male connector interfaces and integrated arrester circuitry, this antenna delivers maintenance-free service life exceeding typical plastic alternatives by 3–5x.
How quickly can I receive samples for testing before placing a bulk order?
Standard specification samples of this 860MHz–930MHz FRP fiberglass antenna ship within 3 business days from stock. Customized prototypes with modified frequency, connector, or mounting configurations are delivered within 5–7 business days after design confirmation. We maintain strategic inventory of core components to accelerate turnaround, and all samples undergo identical QC testing as mass production units to ensure performance consistency. Contact us via WhatsApp or email for immediate sample requests and technical datasheets.
Is this antenna compatible with major LoRaWAN gateway brands like RAK, Kerlink, and Cisco?
Yes, this N Male 860MHz–930MHz fiberglass antenna is fully compatible with all major LoRaWAN gateway manufacturers including RAKwireless, Kerlink, Cisco IR1101, Multitech, and Laird. The standard N Male connector and 50Ω impedance match industry specifications, while the 5.8dBi gain falls within recommended parameters for urban and suburban gateway deployments. We also provide adapter cables for gateways using SMA or RP-SMA interfaces upon request.
Available for OEM/ODM customization. Full technical datasheet provided upon request.
Contact: Minna Liao
Email: minna_liao@bjdz.top
WhatsApp / WeChat: +86 186 2128 3578
