BJDZ is committed to becoming a leading enterprise in the domestic and internationally renowned RF coaxial cable industry, as well as a supplier of electronic cable application solutions. The company's main products are RF coaxial cables, including fine RF coaxial cables, extremely fine RF coaxial cables, semi flexible and semi rigid RF coaxial cables, stable phase microwave RF coaxial cables, military standard series RF coaxial cables, and other series of products. The product has been widely used in consumer electronics, aerospace, data communication, base station communication, and medical systems.
| Structure parameters | ||
| Item | Material | Diamenter (mm) |
| Inner Conductor | Copper clad steel | 0.28 |
| Dielectric | PTFE | 0.86 |
| Outer Conductor | Tin plated copper wire weaving | 0.1 |
| Jacket | PVC | 1.1 |
| Performance parameters | ||
| Capacitor | 32pF/m | |
| Impedance | 50ohm | |
| Transmission rate | 70% | |
| Cut-off frequency | 20GHz | |
| Delayed | 4.7ns/m | |
| Working temperature range | -40～+100℃ | |
| Bending radius | 40mm | |
| ROHS/CE/FCC | YES | |
| Frequency | 0.5GHz | 25dB/100ft |
| 1GHz | 36dB/100m | |
| 30GHz | 65dB/100m | |
Flexible coaxial cables play an important role in modern electronics and communication fields due to their superior performance and wide application scenarios. Understanding their basic structure, working principles, and application areas can better understand the value behind this technology. When selecting and using flexible coaxial cables, paying attention to their characteristics and maintenance requirements will help improve the overall performance and reliability of the equipment.
