Key attributes
| Conductor Material | Copper |
| Insulation Material | PTFE |
| Jacket | PVC |
| Number of Conductors | 1 |
| Model Number | Customize Coaxial Cable extension Assembly |
| Cable Type | Customize |
| Brand Name | BJDZ |
| Place of Origin | Jiangsu, China |
| Application | RF |
| Plating | Nickel |
| Material | Copper |
| Insulator | PTFE/Plastic |
| Certificate | CE/FCC/ROHS/ISO9001:2015 |
| Length | Customize |
| Frequency Range (MHz) | DC-12.5GHz |
| Max Voltage | 335V max |
| Temperature range | -55~+155°C (PE Cable -40~+85°C) |
| Input Impendence (ohm) | 50 |
| V.S.W.R | 1.15+0.02f |
| Vibration | 100m/s2 (10~500Hz) |
| Withstand Voltage | 2500V r.m.s at sea level |
| Working Voltage | 1000Vr.m.s at sea level |
| Insertion Loss | ≤ 0.24dB/6GHz |
| Insulation resistance | ≥5000mΩ |
| Max Input Power (w) | 50 |
| Contact resistance | Center Contact ≤3mΩ |
| Center conductor retention force | 450N |
| Durability | ≥ 500(cycles) |
| Contact resistance | CenterContact ≤1mΩ Outer Contact ≤1mΩ |
| Voltage Standing Wave Ratio | Straight ≤ 1.15/6GHz Right angle ≤ 1.25/6GHz |
Packaging and delivery
| Selling Units | Single item |
| Selling Units | 11X11X11 cm |
| Selling Units | 0.080 kg |
Lead time
| Quantity (pieces) | Lead time (days) |
| 1 - 1000 | 10 |
| 1001 - 5000 | 15 |
| 5001 - 10000 | 25 |
| > 10000 | To be negotiated |
Price
| 1 - 99 pieces | $3.00 |
| 100 - 999 pieces | $2.54 |
| 1000 - 4999 pieces | $2.20 |
| >= 5000 pieces | $1.98 |
Build Your Perfect RF Cable Solution
This fully customizable RF cable assembly allows you to specify your desired connector types (RP SMA, MCX, MMCX, BNC, TNC, N, UHF, F, FAKRA) and cable types (RG316, RG174, RG178, RG58) to meet exacting requirements for WiFi antenna installations. Engineered for low signal loss, high-frequency compatibility, and robust durability, this solution ensures reliable connectivity for indoor/outdoor WiFi systems, access Each cable is precision-built to your specs, with options for length, shielding, and termination. ROHS-certified materials ensure environmental compliance.
1. Connector Options:
Connector A: Choose from RP SMA (Male/Female), MCX, MMCX, BNC, TNC, N, UHF, F, FAKRA (Male/Female).
Connector B: Match with a different connector type for seamless interoperability (e.g., RP SMA Female to BNC Male).
Connector Materials: Brass, stainless steel, or nickel-plated for corrosion resistance.
2. Cable Options:
RG316 (50 Ohm): Ultra-low loss, thin diameter, ideal for high-frequency WiFi (5GHz, 6GHz), aerospace, or test equipment.
RG174 (50 Ohm): Smaller size, flexible, suitable for tight spaces but with slightly higher loss than RG316.
RG178 (50 Ohm): Ultra-flexible, thinner than RG174, ideal for dynamic applications but with higher loss at high frequencies.
RG58 (50 Ohm): Cost-effective, standard for shorter runs, suitable for lower-frequency WiFi (2.4GHz) or budget installations.
3. Cable Length:
Specify your required length (e.g., 1m, 3m, 10m, custom lengths). MOQs may apply for non-standard lengths.
4. Additional Features:
Shielding: Double-shield (foil + braid) or triple-shield options for maximum EMI/RFI protection.
Jacket Material: PVC (standard), Plenum (LSZH for fire safety), or Teflon (high-temperature environments).
Termination: Crimp, solder, or field-attachable options.
1. Optimized for WiFi Frequencies:
RG316: Minimal loss at 2.4GHz, 5GHz, and 6GHz, preserving signal integrity for high-speed WiFi.
Connector Compatibility: Ensure perfect mating with WiFi antennas, routers, access points, or extenders.
2. Durability & Environmental Resistance:
Robust Connectors: Threaded or bayonet locks (e.g., BNC, TNC) for secure connections in outdoor installations.
Temperature Range: Operate reliably from -55°C to +105°C (dependent on cable jacket).
Corrosion Protection: Nickel-plated connectors resist moisture and oxidation.
3. Precision Engineering:
Impedance Matched: All components maintain 50 Ohm impedance for minimal reflections.
Low Insertion Loss: RG316 cables offer ≤ 0.6 dB/m at 2.4GHz, reducing data throughput loss.
VSWR ≤ 1.2:1: Maximize power transfer efficiency.
4. Eco-Friendly & Compliant:
ROHS Certification: Hazardous-free materials meet global environmental regulations.
Enterprise WiFi: Connecting access points to remote antennas in warehouses, office buildings, or campuses.
Outdoor WiFi: Extending cables between routers and outdoor antennas for long-range coverage.
IoT Deployments: Linking WiFi gateways to antennas in industrial or agricultural environments.
WiFi Testing: Connecting spectrum analyzers or network analyzers to WiFi devices for calibration.
Home Networks: Custom cables for DIY antenna upgrades or signal boosters.
Select Your Specs: Choose connectors, cable type, length, and features.
Quote Request: Contact us with your requirements or use our online quote tool.
Engineering Review: Our team will validate your design for performance and manufacturability.
Sample Option: Request a prototype for testing (optional).
Production & Delivery: Manufacture your cables in our ISO-certified facility with 48-hour shipping for stock items.
Packaging: Coiled in static bags with protective caps. Custom labels include specs.
Lead Time: Stock components ship within 2 days. Custom orders: 5–10 days (depending on complexity).
Bulk Orders: Palletized shipping with custom packaging options.
Q1: Can I mix connector genders (e.g., RP SMA Male to MCX Female)?
A: Yes. Specify your required gender combinations during customization.
Q2: What’s the minimum order quantity (MOQ) for custom lengths?
A: MOQs vary by cable type and length. Contact us for details.
Q3: Are the cables suitable for 6GHz WiFi 6E applications?
A: Yes. RG316 cables support frequencies up to 6 GHz with minimal loss, making them ideal for WiFi 6E.
Q4: Can connectors be angled (e.g., 90°)?
A: Yes. Specify angled connectors during customization (additional costs may apply).
Click Here to Customize Your RF Cable or Contact Us for Expert Advice.
