Micro coaxial cables, as an important signal transmission medium, play a crucial role in various fields such as communication, monitoring, broadcasting, and data centers. Its excellent electrical performance and flexible application characteristics make it an indispensable component of modern technology.
| Structure parameters | ||
| Item | Material | Diamenter (mm) |
| Inner Conductor | Bare copper wire | 0.08 |
| Dielectric | EPE | 0.68 |
| Outer Conductor | Tin plated copper wire weaving | 0.88 |
| Sheath | PE | 1.13 |
| Performance parameters | ||
| Capacitor | 95.6pF/m | |
| Impedance | 50ohm | |
| Transmission rate | 70% | |
| Operating Frequency | 6Ghz | |
| Maximum working voltage | 1000Vrms | |
| Working temperature range | -55～+200℃ | |
| Bending radius | 4mm | |
| ROHS/CE/FCC | YES | |
| Decay | 1GHz | 2.3dB/m |
| 2GHz | 3.1dB/m | |
| 3GHz | 3.9dB/m | |
We have strict requirements for product materials, performance, and design. We use advanced computer simulation algorithms and structural optimization to improve RF solutions, and have accumulated years of structural solutions and unique manufacturing processes to further optimize RF indicators. We often conduct pre design manufacturing and cost analysis, and customize corresponding products according to different customer needs, demanding the strictest standards for our own product quality.
Assembly line: We have a professional assembly OEM production base that can provide you with high-quality RF and microwave component processing services.
