Precision Connection: Factory-grade SMB male panel/chassis mount plug seamlessly interfaces with U.FL (U.FL/IPEX/IPX) female socket for compact RF systems.
Optimized RF Performance: 50Ω impedance, low VSWR (<1.35:1), and stable signal transmission across 0–6 GHz frequency range — ideal for WiFi 6, IoT modules, and 2.4/5.8 GHz wireless devices.
Key attributes
| Conductor Material | Copper |
| Insulation Material | PTFE |
| Jacket | PVC |
| Number of Conductors | 1 |
| Model Number | SMB Male to U.FL for 1.13 Pigtail Cable |
| Cable Type | 1.13 mm Cable |
| Brand Name | BJDZ |
| Place of Origin | Jiangsu, China |
| Application | RF |
| Plating | Nickel |
| Material | Copper |
| Insulator | PTFE/Plastic |
| Certificate | CE/FCC/ROHS/ISO9001:2015 |
| Length | 10CM |
| Frequency Range (MHz) | DC-6GHz(semi-rigid cable DC-18 GHz) |
| Max Voltage | 335V max |
| Temperature range | -55~+155°C (PE Cable -40~+85°C) |
| Input Impendence (ohm) | 50 |
| V.S.W.R | 1.15+0.02f |
| Vibration | 100m/s2 (10~500Hz) |
| Withstand Voltage | 2500V r.m.s at sea level |
| Working Voltage | 1000Vr.m.s at sea level |
| Insertion Loss | ≤ 0.24dB/6GHz |
| Insulation resistance | ≥5000mΩ |
| Max Input Power (w) | 50 |
| Contact resistance | Center Contact ≤3mΩ |
| Center conductor retention force | 450N |
| Durability | ≥ 500(cycles) |
| Contact resistance | CenterContact ≤1mΩ Outer Contact ≤1mΩ |
| Voltage Standing Wave Ratio | Straight ≤ 1.15/6GHz Right angle ≤ 1.25/6GHz |
Lead time
| Quantity (pieces) | Lead time (days) |
| 1 - 1000 | 10 |
| 1001 - 5000 | 15 |
| 5001 - 10000 | 25 |
| > 10000 | To be negotiated |
Price
| 20 - 499 pieces | US$1.52 |
| 500 - 4,999 pieces | US$1.25 |
| 5,000 - 9,999 pieces | US$1.19 |
| >= 10,000 pieces | US$1.15 |
Packaging and delivery
| Selling Units | Single item |
| Single package size | 10X2X2 cm |
| Single gross weight | 0.030 kg |
High-Quality Cable: 1.13mm diameter RG178 coaxial cable with fluorinated ethylene propylene (FEP) insulation for flexibility, durability, and minimal signal loss (max 1.5dB @ 6 GHz).
Panel-Mount Design: Screw-threaded SMB male connector securely fastens to metal enclosures or PCB panels — eliminates strain on internal RF traces.
25cm Pigtail Length: Ideal for routing antennas away from interference-prone circuit boards while maintaining signal integrity.
Rated for 30 Cycles: Designed for occasional connection/disconnection during prototyping or maintenance — avoid repeated mating to preserve connector life.
Parameter | Value |
Connector Type | SMB Male (Panel Mount) → U.FL Female |
Cable Type | RG178 (1.13mm OD) |
Length | 25 cm (including connectors) |
Impedance | 50 ± 2 Ω |
Frequency Range | DC – 6 GHz |
VSWR | <1.35:1 (full band) |
Max Operating Voltage | 200 V AC / 1 min |
Operating Temperature | -40°C to +90°C |
Mating Cycles | 30 (manufacturer-rated) |
Shielding | Braided copper + foil |
Cable Color | Black (standard) |
WiFi routers & access points with internal U.FL antenna ports
IoT gateways and embedded wireless modules (ESP32, nRF52, CC3000)
Miniature LTE/5G modems and GPS receivers
Drone RF systems and industrial wireless sensors
Prototyping and RF test setups requiring secure panel mounting
Do not force the U.FL connector. It snaps in with light pressure — a distinct “click” confirms proper engagement.
Use tweezers or a non-metallic tool to handle the U.FL end — avoid finger contact with the center pin.
Secure the cable along the chassis with zip ties or adhesive clips to prevent flex fatigue near the connector.
Not recommended for high-vibration environments without strain relief.
Unlike generic jumpers, this cable is engineered for industrial-grade reliability — not just low cost. The SMB panel mount ensures mechanical stability, while the RG178 cable balances flexibility and attenuation performance. Perfect for OEMs, system integrators, and makers deploying wireless solutions in space-constrained enclosures.
