Efficiency: Cable components can optimize signal transmission, reduce energy loss, and ensure that power, data, or audio reaches their destination with minimal interference.
Reliability: The design of cable components is durable, maintaining performance even in harsh environments and providing stable, uninterrupted connections.
| Key attributes | |
| Conductor Material | Copper |
| Insulation Material | PTFE |
| Jacket | PVC |
| Number of Conductors | 1 |
| Model Number | N Type Male Plug to QMA Male Cable Assembly |
| Brand Name | BJDZ |
| Place of Origin | Jiangsu, China |
| Application | RF |
| Frequency Range (MHz) | DC~12.4GHz |
| Max Voltage | 335V max |
| V.S.W.R | ≤1.20+0.003f |
| Withstand Voltage | 1000V rms |
| Max Input Power (w) | 50 |
| Contact resistance | Center Contact ≤3mΩ |
| Center conductor retention force | 450N |
| Durability | ≥ 500(cycles) |
| Contact resistance | Center Contact ≤1mΩ Outer Contact ≤1mΩ |
| Voltage Standing Wave Ratio | Straight ≤ 1.15/6GHz Right angle ≤ 1.25/6GHz |
| Impedance (Ohm) | 50 |
| Velocity(%) | 70 |
| Shielding | 13 |
| Max. Oper. Voltage (VMS) | 1200 |
| Operating Temp. (℃) | -55 to 200 |
| Length | Customized |
| Connector | Customized |
| Certificate | CE/FCC/ROHS/ISO9001:2000 |
| Keywords | network jumper cable |
| Lead time | |
| Quantity (pieces) | Lead time (days) |
| 1 - 1000 | 14 |
| 1001 - 5000 | 15 |
| 5001 - 10000 | 20 |
| > 10000 | To be negotiated |
1. Team R&D Strength: The company integrates independent product technology development and application, attaches importance to independent intellectual property rights, always adheres to independent R&D and continuous innovation, continuously strengthens its own technology investment, and provides professional and reliable products and supporting services for the RF communication industry.
2. Our company has a group of high-precision and advanced professional RF technology developers, and a deep understanding of RF technology theory and application is the core part of current technology.
