Elevate your RF connectivity with our high-precision RG316 RF Jumper Cable Assembly. Designed as a dedicated SMB Female to SMB Female adapter extension, this pigtail antenna cable is the reliable bridge for demanding wireless systems, test setups, and communication networks, ensuring minimal signal loss and maximum durability.
Key attributes
| Conductor Material | Copper |
| Insulation Material | PTFE |
| Jacket | PVC |
| Number of Conductors | 1 |
| Model Number | SMB Female to SMB Female for RG316 cable assembly |
| Cable Type | RG316 cable |
| Brand Name | BJDZ |
| Place of Origin | Jiangsu, China |
| Application | RF |
| Plating | Nickel |
| Material | Copper |
| Insulator | PTFE/Plastic |
| Certificate | CE/FCC/ROHS/ISO9001:2015 |
| Length | 30CM |
| Frequency Range (MHz) | DC-12.4GHz(semi-rigid cable DC-18 GHz) |
| Max Voltage | 335V max |
| Temperature range | -55~+155°C (PE Cable -40~+85°C) |
| Input Impendence (ohm) | 50 |
| V.S.W.R | 1.15+0.02f |
| Vibration | 100m/s2 (10~500Hz) |
| Withstand Voltage | 2500V r.m.s at sea level |
| Working Voltage | 1000Vr.m.s at sea level |
| Insertion Loss | ≤ 0.24dB/6GHz |
| Insulation resistance | ≥5000mΩ |
| Max Input Power (w) | 50 |
| Contact resistance | Center Contact ≤3mΩ |
| Center conductor retention force | 450N |
| Durability | ≥ 500(cycles) |
| Contact resistance | CenterContact ≤1mΩ Outer Contact ≤1mΩ |
| Voltage Standing Wave Ratio | Straight ≤ 1.15/6GHz Right angle ≤ 1.25/6GHz |
Lead time
| Quantity (pieces) | Lead time (days) |
| 1 - 1000 | 10 |
| 1001 - 5000 | 15 |
| 5001 - 10000 | 25 |
| > 10000 | To be negotiated |
Price
| 5 - 999 pieces | US$1.98 |
| 1,000 - 4,999 pieces | US$1.78 |
| 5,000 - 9,999 pieces | US$1.52 |
| >= 10,000 pieces | US$1.50 |
Packaging and delivery
| Selling Units | Single item |
| Package size per batch | 11X11X11 cm |
| Gross weight per batch | 0.100 kg |
This cable assembly is engineered for professionals who require a robust and flexible connection solution. It features a high-quality RG316 coaxial cable terminated with precision SMB female connectors on both ends. The primary function is to extend, connect, or adapt between two devices with SMB female ports, commonly found in antennas, transceivers, GPS modules, LTE equipment, and various RF testing instruments.
The core benefits are clear: superior signal integrity up to 6 GHz, excellent flexibility for routing in tight spaces, and a durable construction that resists environmental stress. It solves common connectivity gaps, eliminates the need for mismatched adapters, and provides a streamlined, low-loss link for your critical RF pathways.
For engineers and procurement specialists, here are the precise specifications that define this product's performance:
Connector Type: SMB Female Jack (Plug) to SMB Female Adapter (Jack). This configuration is ideal for creating extensions or connecting two female-port devices via a single, integrated cable.
Cable Type: Premium RG316/U Coaxial Cable.
Impedance: 50 Ohms, standard for most RF applications.
Frequency Range: DC to 6 GHz, covering critical bands for Wi-Fi, 4G/5G, GPS, and IoT communications.
Cable Length: Available in multiple standard lengths (e.g., 0.15m, 0.3m, 0.5m, 1m). Custom lengths are available for bulk OEM orders.
Inner Conductor: Silver-plated copper-clad steel.
Dielectric: Solid PTFE (Teflon), ensuring stable performance across temperature variations.
Shielding: Dual-layer shielding (braid + foil) for superior EMI/RFI protection.
Outer Jacket: Flexible, abrasion-resistant PVC, suitable for various indoor environments.
Operating Temperature: -40°C to +85°C.
Voltage Rating: 500 V RMS.
Minimum Bend Radius: 10mm.
This versatile jumper cable is indispensable across numerous industries:
Telecommunications: Extending connections between base station antennas and RF units.
Wireless Networking: Linking Wi-Fi access points, routers, and external high-gain antennas.
GPS & Satellite Systems: Connecting GPS receivers to external passive or active antennas for improved signal reception.
Test & Measurement: Essential in lab environments for connecting spectrum analyzers, signal generators, and device under test (DUT).
IoT & M2M Devices: Providing reliable antenna connections for industrial sensors, remote monitors, and data loggers.
Broadcast & Surveillance: Used in CCTV systems with wireless video transmitters and other broadcast equipment.
Optimized Signal Integrity: The RG316 cable and precision SMB connectors are matched for 50-ohm impedance, minimizing VSWR and insertion loss.
Durable Construction: Features gold-plated contacts for excellent corrosion resistance and stable electrical performance, housed in brass connector bodies with a robust PVC jacket.
Ready-to-Use Assembly: Factory-assembled and tested, saving you time and ensuring consistent quality compared to field-assembled cables.
Flexible & Compact: The slim and flexible RG316 cable is perfect for tight spaces and moving applications without compromising performance.
Cost-Effective Solution: Provides a more reliable and cleaner alternative to using multiple separate adapters, reducing potential failure points.
Upgrade your RF system's reliability with our RG316 RF Jumper Cable SMB Female to SMB Female. This high-frequency adapter extension cable is engineered for seamless integration between SMB-compatible devices. As a manufacturer-direct supplier, we guarantee top-tier quality in this antenna pigtail assembly, designed for low loss and high shielding effectiveness. Ideal for extending antenna leads, connecting RF modules, or serving as a test port extension in demanding environments from DC to 6GHz. Search for a durable, flexible, and high-performance SMB female jumper cable—your solution for robust RF interconnects is here.
We are a direct manufacturer, ensuring competitive pricing and consistent supply. This product is available for immediate shipment in standard lengths. For large volume projects, OEM customization, or specific length requirements, please contact our sales team for a personalized quote. Every cable is 100% tested to meet specified performance criteria.
Compatibility Note: This cable connects two devices with SMB female ports. To connect an SMB male plug to another SMB male plug, a different cable (SMB Male to SMB Male) would be required.
