Engineered for critical high-frequency applications, this Microdot to 10-32 Cable Assembly delivers superior signal integrity in compact electronic systems. Utilizing high-grade RG178 coaxial cable, this pigtail is specifically designed for environments requiring miniaturization without sacrificing performance. Perfect for medical instrumentation, aerospace sensors, and high-density PCB interconnects, this cable ensures reliable transmission in the most demanding spaces.
Cable Type: RG178 Coaxial Cable (High-Frequency, Ultra-Flexible)
Connector A: Microdot Plug (Compact, High-Density Interface)
Connector B: 10-32 UNF / M5 Plug (Standard for Miniature Probes & Sensors)
Impedance: 50 Ohm
Frequency Range: DC to 3 GHz (Optimized for RF Signal Transmission)
VSWR: ≤ 1.30 (Excellent Signal Return Loss)
Insulation: PTFE (Polytetrafluoroethylene) for High-Temperature Stability
Shielding: High-Density Tinned Copper Braid (Superior EMI/RFI Protection)
Jacket: Fluorinated Ethylene Propylene (FEP), Flexible & Durable
Operating Temperature: -55°C to +200°C
Micro-Miniature Design for High-Density Applications
The Microdot to 10-32 Cable Assembly is the ultimate solution for connecting miniature electronic components where space is at a premium. The Microdot connector is renowned for its incredibly small footprint, making it ideal for integration into portable medical devices, aerospace avionics, and compact RF modules. Paired with the industry-standard 10-32 UNF (M5) interface, this cable provides a seamless bridge between high-density circuit boards and external sensors or antennas.
Superior Signal Performance with RG178
Performance is paramount in high-frequency circuits. This assembly utilizes RG178 coaxial cable, known for its low loss characteristics and excellent phase stability. The PTFE dielectric ensures minimal signal attenuation, while the robust shielding prevents electromagnetic interference. This results in a clean, stable signal path essential for precision measurement equipment, radar systems, and high-speed data acquisition.
Manufactured in Zhenjiang, Jiangsu
Crafted in our facility located in Zhenjiang, Jiangsu, this cable assembly benefits from strict quality control standards synonymous with Chinese industrial manufacturing. We utilize automated soldering and crimping equipment to ensure consistent contact resistance and mechanical strength. Every batch undergoes rigorous electrical testing to guarantee it meets the stringent requirements of global B2B clients.
Extreme Environment Ready: The FEP jacket and PTFE insulation make this cable resistant to high temperatures, chemicals, and abrasion.
Low Voltage Standing Wave Ratio (VSWR): Ensures maximum power transfer with minimal signal reflection.
Custom Lengths Available: We support "Small Batch, Multi-style" orders to fit your specific device housing or chassis layout.
Fast Lead Times: Leveraging our automated production lines in Zhenjiang, we offer rapid turnaround for both samples and bulk orders.
Medical Devices: Connecting miniature probes in endoscopes, surgical tools, and diagnostic equipment.
Aerospace & Defense: Signal transmission in avionics, UAVs, and radar warning receivers.
Industrial Sensors: Interfacing with high-precision pressure sensors, accelerometers, and transducers.
Telecommunications: RF jumpers for base stations and microwave communication modules.
Standard Packaging: Individual anti-static bags to protect sensitive RF components, packed in export-standard cartons.
Custom Packaging: Available for branded retail or specific logistics needs.
Lead Time: 3-5 days for sample preparation; 10-15 days for mass production.
Origin: Zhenjiang, Jiangsu, China.
Q1: What is the difference between Microdot and Microdot 10-32 connectors?
A: "Microdot" refers to the connector series, known for its small size. "10-32" refers to the thread size (10-32 UNF) commonly used on the mating receptacle, often found in miniature probes. This cable features a Microdot plug on one end and a 10-32 threaded coupling nut on the other.
Q2: Is this cable suitable for high-temperature medical sterilization?
A: The RG178 cable with PTFE/FEP construction has a high-temperature rating (up to 200°C). However, for specific sterilization processes (like autoclaving), please verify the temperature limits of your specific device housing.
Q3: Can you customize the cable length?
A: Yes, we specialize in OEM/ODM services. Whether you need a 10cm pigtail for an internal circuit or a 2m cable for external connectivity, we can manufacture to your exact specifications.
Q4: What testing does this cable undergo?
A: Every cable assembly is subjected to 100% Continuity Testing and Hi-Pot (Dielectric Withstanding Voltage) testing to ensure there are no shorts or opens before shipment.
