The BJDZ series and inter series coaxial adapters are specifically designed to meet the needs of any RF application. These adapters have consistent electronic performance and optimized mechanical reliability, and can be used to transfer common coaxial connectors such as BNC, SMA, Type N, and TNC.We specialize in the research and development, production, and sales of microwave devices such as RF connectors, RF adapters, RF jumper cables, antenna，lightning arresters, directional couplers, power dividers, synthesizers, and duplexers.
| Structure parameters | ||
| Item | Material | Diamenter (mm) |
| Inner Conductor | Copper clad steel | 7*0.17 |
| Dielectric | PE | 1.52 |
| Outer Conductor | Tin plated copper wire weaving | 1.9 |
| Jacket | PVC | 2.79 |
| Performance parameters | ||
| Capacitor | 101.05pF/m | |
| Impedance | 50ohm | |
| Transmission rate | 66% | |
| Maximum operating voltage | 1.1KVrms | |
| Maximum operating frequency | 1000MHz | |
| Working temperature range | -25～+70℃ | |
| Bending radius | 10mm | |
| ROHS/CE/FCC | YES | |
| Frequency | 100MHz | 0.276dB/m |
| 400MHz | 0.558dB/m | |
| 1000MHz | 0.899dB/m | |
Technical Strength: Experienced R&D team and standardized laboratories provide one-stop service from prototype development to mass production;
Quality Assurance: Strict adherence to ISO/IEC international standards ensures that products achieve industry-leading levels in weather resistance, signal stability, and other key indicators;
