High-Performance RF Connector Solution for Diverse Telecommunication and Industrial Applications
This comprehensive RF connector assembly offers unparalleled versatility and reliability, designed to meet the stringent demands of modern communication systems. Compatible with N Type, SMA, BNC, TNC, 7/16 Din, 4.3-10, and Mini Din connectors in both male and female configurations, this assembly ensures seamless integration across a wide range of equipment. Engineered specifically for 086 RG402 and RG405 semi-rigid/flex cables, it excels in maintaining signal integrity even in tight spaces or dynamic environments, making it ideal for applications requiring exceptional flexibility and durability.
Key attributes
| Conductor Material | Copper |
| Insulation Material | PTFE |
| Jacket | PVC |
| Number of Conductors | 1 |
| Model Number | Semi Rigid Flex Cable Assembly |
| Cable Type | Semi Rigid Flex Cable |
| Brand Name | BJDZ |
| Place of Origin | Jiangsu, China |
| Application | RF |
| Plating | Nickel or Tri-Metal plated |
| Material | Copper |
| Insulator | PTFE/Plastic |
| Certificate | CE/FCC/ROHS/ISO9001:2015 |
| VSWR | 1.15+0.02f |
| Vibration | 98m/S2 (10~2000Hz), 10g |
| Frequency Range (MHz) | DC-3-18GHz |
| Max Voltage | 335V max |
| Temperature range | -55~+155°C (PE Cable -40~+85°C) |
| Input Impendence (ohm) | 50 |
| V.S.W.R | 1.15+0.02f |
| Vibration | 98m/S2 (10~2000Hz), 10g |
| Insertion Loss | ≤ 0.15dB/6GHz |
| Withstand Voltage | 1000V rms |
| Working Voltage | 335Vr.m.s at sea level |
| Insulation resistance | ≥5000mΩ |
| Max Input Power (w) | 50 |
| Contact resistance | Center Contact ≤3mΩ |
| Center conductor retention force | 450N |
| Durability | ≥ 500(cycles) |
| Contact resistance | CenterContact ≤3mΩ Outer Contact ≤2.5mΩ |
| Voltage Standing Wave Ratio | Straight ≤ 1.15/6GHz Right angle ≤ 1.25/6GHz |
Packaging and delivery
| Selling Units | Single item |
| Single package size | 111X10X10 cm |
| Single gross weight | 1.00kg |
Lead time
| Quantity (pieces) | Lead time (days) |
| 1 - 1000 | 10 |
| 1001 - 5000 | 15 |
| 5001 - 10000 | 25 |
| > 10000 | To be negotiated |
Multi-Standard Compatibility: Supports industry-standard connectors (N Type, SMA, BNC, TNC, 7/16 Din, 4.3-10 Mini Din) to streamline cross-system connectivity.
Semi-Rigid/Flex Cable Compatibility: Precision-engineered for 086 RG402 and RG405 cables, offering superior bendability without signal loss, suitable for space-constrained installations.
Robust Flange Mount Design: Enhanced stability and secure mounting via flanged connectors, reducing vibration risks and ensuring long-term reliability.
Low PIM & High-Frequency Performance: Optimized for minimal passive intermodulation distortion (PIM), delivering consistent performance across wide frequency ranges (up to XX GHz, as specified).
Durable Construction: Manufactured with corrosion-resistant materials and precision machining, withstanding harsh environments (temperature range: XX to XX°C) and repeated mating cycles.
Industry Compliance: Meets stringent quality certifications (ISO9001, RoHS, etc.) and is 100% tested for impedance matching (50Ω/75Ω, as applicable).
Data centers and server farms
Wireless communication infrastructure (5G/6G)
Aerospace and defense systems
Broadcasting and telecommunications
Industrial IoT and automation
Test and measurement equipment
Connector Types: N Type/SMA/BNC/TNC/7/16 Din/4.3-10 Mini Din (Male/Female)
Cable Compatibility: 086 RG402, RG405 (Semi-Rigid/Flex)
Impedance: 50 Ω (as specified)
Frequency Range: Up to 18 GHz (depending on connector type)
Interface Material: Brass/Copper Alloy (Gold-Plated)
Jacket Material: High-Density Polyethylene (HDPE) with Flexible Armor
Operating Temperature: -55to 155°C
VSWR (Typical): ≤1.15+0.02f
Unmatched Flexibility: Adapts to diverse cable types and connector standards.
Signal Fidelity: Low-loss design ensures maximum data throughput.
Industrial-Grade Durability: Designed for extended use in challenging conditions.
Global Certification: Compliance with international quality and safety norms.
Cost-Effective: Optimized for reliability and longevity, minimizing downtime.
Supplied By:
Zhenjiang Binjiang Electronic Co., Ltd. — Your Trusted Partner for RF Excellence.
Connect with Confidence. Deliver on Performance.
