| Product Name | SSMA Connector |
| Frequency Range | DC-40GHz |
| Impedance | 50Ω |
| VSWR | 1.20:1(max) |
| Dielectric withstand voltage | 1000v |
| Service life | >500 times |
| Insulation Resistance | >5000Ω |
| A connector type | SSMA-male |
| B connector type | removable |
| Operation Temperature | -55°C-+165℃ |
| Inner conductor material | Beryllium bronze Gold plating |
| External conductor material | Stainless steel Passivation |
| Insulator | PTFE |
1. Due to its compact size and ease of quick connection/disconnection, SSMA connectors are more suitable for high-density circuit board applications with limited space, such as satellite communication devices, wireless local area network (WLAN) base stations, and military communication systems.
2. The miniaturization design of SSMA connectors may result in slightly inferior performance compared to SMA connectors in certain high-frequency bands, such as millimeter wave frequencies. But in most conventional applications, the performance difference between the two is not significant.
